The return air chase (aka “the return” or “return”) is the box or space located directly behind your air filter. Some returns are designed to work in the ceiling and others are located on a wall. Most often this space is in a common area of your home. Your thermostat should be located near the return filter.

What is a ventilation chase?

What is a chase, you ask? For direct vent gas fireplaces, it is an insulated structure that houses the fireplace. Built according to careful specifications, a chase can either be added to the exterior of the home (a mini-chase), or installed into the living space (a reverse or interior chase).

What is a HVAC return?

When your HVAC system blows air into your home, that changes the air pressure inside. The excess air needs somewhere to go, and that spot is the return vent. The return vent is usually bigger than your supply vents because it’s how the air handler sucks air into the HVAC system.

What is a plenum in an AC unit?

Plenum boxes are usually situated on either side of the fan or heat exchanger and have the important function of bringing in, distributing, and removing air. They are the air’s first stop after being heated or cooled and its last stop before going back into your AC, heat pump, or furnace.

What is included in HVAC rough in?

The HVAC rough in period refers to when the HVAC ductwork has been installed, yet no plumbing, electrical, or exterior walls have been put into place. This is so that inspectors can have a much easier time coming in and going over each aspect of the ductwork, making sure that it is not contaminated and is fit for use.

Should chimney chase be insulated?

“If the climate in your area is very cold, insulate the chase to the top to keep the chimney warmer, increase the draft, and reduce creosote buildup. We also recommend to insulate the ceiling of the chase just as if it were in the attic space.

Should a chimney chase be vented?

Then vent the chase to the inside of the house, through the wall between it and the house. This would make the chase part of the house’s heated envelope, giving you the draft of an interior chimney. At the very least it would be warmer and draw better than if your chase were directly vented to exterior air.

Are plenums necessary?

Q: Is a plenum necessary? A: In modern forced-air HVAC systems, you must have a plenum installed.

What is the vent on the outside of my fireplace for?

Keeping a fire lit takes different factors including air and fuel for burning. The products of combustion include water vapor and carbon monoxide. … An outside air source is a vent that provides fresh air to feed the fire.

Why do we use plenum in HVAC?

Plenum boxes are used to distribute heated or cooled air throughout your home’s interior. After producing heated or cooled air, the HVAC system must move that air through the ductwork. Plenum boxes take in this air so that it can be pumped into the ductwork and, therefore, distributed throughout your home’s interior.

Article first time published on

What is the purpose of plenum?

In building construction Plenum is a separate space provided for air circulation for heating, ventilation, and air-conditioning. It is commonly found in the space between the structural ceiling and a drop-down ceiling or under a raised floor.

Does every room need a heat vent?

If you have a ducted heating or cooling system, you should install a supply vent in every room. This allows for the most efficient heating or cooling of your home and saves money in the long run. However, you do not need vents to provide fresh air into a room.

What happens if there is not enough return air?

If there is not enough return air available, your HVAC system will not heat or cool properly. … If not enough air is brought back, your HVAC system will not be able to keep up with temperature demands. In some cases, two returns may be necessary to provide enough return air.

Why do you need Return air vents?

Return air vents are an important part of your HVAC system. These vents allow the air that is in your home to return to the system for heating or cooling in order to maintain the proper temperature in the home. … A fan or blower inside the HVAC system draws air into the cold air return or return air vent.

Do you need a cold air return in every room?

While it is a myth that air return grilles are required in each and every room in the house, it is definitely necessary to have more than one of these grilles installed at strategic places in the house. … Likewise, you can also install these in rooms that have a high footfall or usage in the house.

Can you put a cold air return in the floor?

Where are cold air returns located? Cold air returns are located on interior walls in a home, typically close to the floor or low on the wall. You want to make sure that cold air return vents are not blocked or covered by furniture so that your home can get proper air circulation.

How much does it cost to reroute HVAC?

Depending on the length and size of the duct, as well as whether or not additional labor is involved to maneuver through floorboards and walls, individual duct runs generally cost anywhere from $300 to $1,200, though this is an average.

How much does it cost to install central air with ductwork?

Install new ductwork and a central AC system. Homeowners can expect to pay anywhere between $3,000 to $10,000 for ductwork installation.

What are fit offs?

The fit-off is the usually final stage for your plumbing and gas service on your renovation or new build . This is when we install all of your gas appliance such as gas stove, oven, hot water system, and install fixtures such as gas Bayonet for a bbq point.

How much does it cost to install ductwork?

The national average cost for installing ductwork is between $1,900 and $6,000, with most homeowners spending around $4,000 for the professional installation of 300 linear feet of replacement aluminum ducts, insulation, and 10 vents and 2 returns.

How much does it cost to replace a chimney chase cover?

Chimney Chase Cover or Cap Replacement Cost Expect to pay $150 to $200 with installation for a new chimney cover. The cover (sometimes called a cap) protects your flue and is at the very top of the chimney.

What is the chimney chase?

A chimney chase is a chimney by any other name, but usually one built of framed wood or siding. It is essentially a prefab chimney made of wood.

How much does it cost to build a chimney chase?

Chimney Installation CostNational average cost$6,500Average range$4,000 – $8,000Minimum cost$3,500Maximum cost$11,500

How do I stop cold air coming down my chimney?

Another great way to block cold air is with a chimney balloon or plug. These devices are placed above the throat damper and inflated to completely block air from coming down into your fireplace. Balloons are designed to be used only when a fire isn’t burning.

Can you use spray foam around chimney?

To keep a fireplace working properly, never use spray foam on the inside of the fireplace or the chimney, or on the damper. On the exterior surfaces of the fireplace and chimney, spray foam is fine because these surfaces won’t get hot enough to melt it or to cause any damage.

Does a fireplace need a fresh air vent?

Fresh Air Vent Needed for Fireplaces A fireplace consumes vast amounts of air each minute as the fuel burns. It can easily be 250 to 350 cubic feet of air per minute. The fresh air vent in the hearth may be blocked or it may not be able to supply enough air to satisfy the appetite of the fire.

Why is there a vent in the back of my fireplace?

A fully open vent allows the smoke to travel up the chimney. It also allows fresh air to feed the fire and keep it burning.

When should I close my fireplace vent?

The damper should always be fully open before lighting a fire and when the fireplace is in use. Close it when it’s not it use. Operating the fireplace with the damper partially closed will not generate more heat. Instead, blocking the passage through the flue will result in smoke entering the home.

How do you remove mold from plenum?

Use an EPA registered disinfectant labeled for HVAC use to clean non-porous surfaces (Ductwork, coils, plenums, pans, etc) of mold, mildew, and other dirt. BIOSPRAY-TOWER ready-to-use disinfectant and mold cleaner will kill and remove mold, mildew, and odor-causing bacteria.

How big should a plenum be?

Single plenums should not exceed 24 ft in length. Double plenums should not exceed 48 ft in total length.

What is a transition HVAC?

Biyang Duct Transition, also called Duct Connector is a critical and indispensable part of HVAC ductwork. It connects the different sizes of ducting, different parts of facilities, and different materials of ventilation components together to ensure the smooth and steady air flow.
