For example, for an unbalanced 24F layup using visually graded Douglas-fir lumber, the layup designation is identified as a 24F-V4. The “V” indicates that the layup uses visually graded lumber. A 24F-E4 beam would indicate a mechanical graded lumber.

What is 24F V4?

24F-V4 1.7E Industrial Glulam Beam. SKU: IGL3121178169. Glulam is an engineered wood product that optimizes the structural values of a renewable resource (wood). Length. 16′ 9″

Can you install a glulam upside down?

I installed my glulam beam upside down, is it ok? By installing the beam upside down, you lose approximately 25% of the beam strength. If possible, flip the beam to the correct orientation.

Is glulam the same as LVL?

LVL refers to a manufactured timber product made from thin veneers (often 3mm) glued together to form large structural members, often known as Hyspan or similiar. Glulam is made from thicker sections of timber, generally 15-45mm thick, glued together to form a large variety of products.

Can you rip a glulam?

Can I rip it to a shallower depth? Should I remove the excess depth from the top or from the bottom? The removal of laminations from glulam beams is generally not recommended. Glulam beams are typically manufactured with the highest quality laminations placed at the top and bottom of the section.

Do glulam beams have a top?

Unbalanced Glulam Beams To assure proper installation of unbalanced beams, the top of the beam is clearly stamped with the word “TOP.” Unbalanced beams are primarily intended for simple span applications.

How much does glulam cost?

TypeCost Per Linear FootLVL$3 – $12Glulam$6 – $34

Is glulam more expensive than steel?

Is glulam cheaper than steel? For a simple beam, spanning between supports, glulam is often cheaper than steel. … For fabricated structures glulam is usually a little more expensive than steel.

What is a PSL beam?

Parallel-strand lumber (PSL) is a form of engineered wood made from parallel wood strands bonded together with adhesive. It is used for beams, headers, columns, and posts, among other uses. … It is a member of the structural composite lumber (SCL) family of engineered wood products.

How much stronger is glulam?

In terms of strength, Glulam timber is one-sixth the weight of concrete and one-tenth the weight of steel, and is stronger than steel due to its greater stiffness and strength.

Article first time published on

Can you nail into a glulam beam?

Plus, it’s easy to connect other wood floor-framing components to glulam because the wood-to-wood connections can be made with standard carpentry tools and fasteners. Nailers are not needed as they are with steel beams, and nail-on joist hangers can easily be accommodated.

Can I screw into a laminated beam?

Whenever possible, avoid drilling vertical holes through LVL beams unless the beam width is at least 3-1/2 inches. Prior to drilling any vertical holes, an engineer or architect qualified in wood design should be consulted.

Can you paint LVL?

NelsonPine LVL billets in standard thicknesses come with an industrial type finish that can have normal timber paint and stain systems satisfactorily applied to them. Enhancement of the visual appearance and coating adhesion can be achieved by relatively coarse sanding the surface prior to the first coat.

Can LVL beam be ripped?

Manufacturers rip it as standard practice when producing beams. LVL is made in billets up to 48 inches wide that are ripped to commercially available standard depths. It’s okay to rip LVL beams to a smaller depth, too, though you’ll have to recalculate the beam capacity.

Can glulam beams exposed weather?

Guard against direct exposure of glulam members to severe conditions like high temperatures, rain, and other damaging weather conditions. Hot/dry and wet/winter climates can create high-risk environments, depending on how quickly the moisture content changes.

How big of a beam do I need to span 20 feet?

Wood beam size for a 20 foot span:- as per general thumb rule, for a 20 foot span, size of wood beam or lumber joist should be 2×14 which placed at 16″ apart from centre used for residential building or projects or construction in which depth of section of beam is 350mm (14″) and width of beam is 50 mm or 2″.

How heavy is a glulam beam?

Weight of Glulam (Glued Laminated Timber)5-1/2″0.17 lbs27.56-3/4″0.21 lbs33.758-3/4″0.27 lbs43.7510-3/4″0.34 lbs53.75

What is an LVL beam?

Laminated veneer lumber (LVL) is an engineered wood product that uses multiple layers of thin wood assembled with adhesives. It is typically used for headers, beams, rimboard, and edge-forming material. … Due to its composite nature, it is much less likely than conventional lumber to warp, twist, bow, or shrink.

How far can a 4x8 glulam beam span?

In large open spaces, glulam beams can span more than 100 feet. One of the greatest advantages of glulam is that it can be manufactured in a wide range of shapes, sizes and configu- rations.

What is the longest glulam beam?

The largest wood beams ever tested are being studied at the Forest Products Laboratory (FPL). Made of Douglas-fir, the glued laminated (glulam) beams each measured 72-feet-long and weighed in at 6,000 pounds.

What distance can a LVL span?

Due to its strength, an LVL beam can span up to 60 feet and is much stronger than traditional lumber. Generally, you can find LVL beams in 4-foot increments starting at 24 feet and going up to 44 feet long, with special orders up to 60 feet. LVL beam thickness is usually between 1 ¾ and 7 inches.

How heavy is a PSL beam?

SeriesSeries Parallam®Product WidthProduct Width 7″WeightWeight 31 pounds per footBrandBrand Trus Joist®Product Type1Product Type1 Parallel Strand Lumber (PSL)

Is PSL or level stronger?

PSL beams are generally more expensive than glulam, LSL, or LVL beams. … Laminated Veneer Lumber (LVL) is a commonly available engineered product that is manufactured similarly to PSL. Available sizes, strengths, and stiffnesses are similar to PSL but are generally cheaper, making it a commonly specified beam type.

What wood is PSL?

PSL is made from strands bonding together in a continuous press using waterproof adhesives with a phenol-formaldehyde base. It can made using waste materials from plywood and LVL production, with species commonly including Douglas-fir, pine and western hemlock, among others.

Are glulam beams expensive?

Glulam can also be more expensive than traditional lumber. When stained, it can look noticeably different than a solid piece of Timber and has a different aesthetic than solid beams.

Who makes glulam?

As North America’s largest producer of Southern Yellow Pine glue-laminated beams (glulam), Anthony Forest Products Company, LLC (a Canfor Corporation company) engineered wood products operations offer a wide variety of glulam for commercial and residential applications.

Is glulam stronger than timber?

Glulam has been shown to be as strong as steel, with greater strength and stability than similarly sized standard dimensional lumber. … As compared to solid sawn lumber posts, Glulam is a stress-rated engineered wood product composed of layers of bonded wood laminations running the length of the post.

Is LVL stronger than dimensional lumber?

Laminated veneer lumber (LVL) studs can be two times stronger in compression and tension than standard framing lumber of the same dimension.

What lengths do Glulams come in?

Glulam Sizing Typical stock beam widths used in residential construction include: 3-1/8, 3-1/2, 5-1/8, 5-1/2, and 6-3/4 inches. For non-residential applications, where long spans, unusually heavy loads, or other circumstances control design, custom members are typically specified.

What are the disadvantages of glulam?

Quality. The second disadvantage of glulam timber is its quality. Glulam Timber is made by joining several timber pieces. If defective timber is used in the middle of the timber block during production, this malfunctioning timber can cause the entire timber block to deteriorate.

Can you drill a hole in a glulam beam?

As such, glulam beams are generally designed for and used in applications where they will be highly stressed under design loads. … Because of this, any drilling, dapping or notching that takes place in these outermost tension laminations has effects on the strength and serviceability of the beam.
