The North American refrigeration industry uses copper pipe designated ACR (air conditioning and refrigeration field services) pipe and tubing, which is sized directly by its outside diameter (OD) and a typed letter indicating wall thickness.

What is ACR fitting?

The North American refrigeration industry uses copper pipe designated ACR (air conditioning and refrigeration field services) pipe and tubing, which is sized directly by its outside diameter (OD) and a typed letter indicating wall thickness.

What is the difference between ACR and Type L copper?

Copper, used for refrigeration, is designated as ACR copper. Measure the inside and outside diameter of the end of the tube. The outside diameter of Type L is always 1/8-inch larger than the size marked on the tube. … ACR is designed to be sold with no moisture inside the tube.

What is ACR copper fittings?

Copper tube for air-conditioning and refrigeration field service (ACR) is designated by actual outside diameter. “Temper” describes the strength and hardness of the tube. In the piping trades, drawn temper tube is often referred to as “hard” tube and annealed as “soft” tube.

What is Type ACR copper pipe used for?

Type ACR, Coiled, Copper Tubing Air Conditioning and Refrigeration Copper Coils easily connect air conditioning and refrigeration equipment, using sweating or flare fittings.

What is ACR hard drawn copper?

ACR (Air Conditioning and Refrigeration) tubing is charged with nitrogen and sealed. Same as L thickness, it comes in both hard drawn tubing and “soft” rolls of 50′ and 100′. Soft tubing is annealed (heated and then allowed to cool) to make it flexible and easy to bend and flare.

How thick is ACR copper?

Nominal Size (inches)Annealed (A) or Drawn Temper (D)Wall Thickness (inches)5/8D0.0403/4A0.035A0.042D0.042

Which type of copper tubing has the same dimensions as Type ACR?

Which type of copper tubing has the same dimensions as ACR? Type L.

What color is ACR?

As permitted in the ASTM B819 standard, type L OXY/ACR, ACR/MED straight length tubing is ink marked in blue color with a dual stencil that includes both “ACR and OXY/MED”.

In what temper is ACR copper tube available?

ACR Straight Tube is usually supplied in the hard and half hard temper, annealed temper is also available if requested.

Article first time published on

Can you use ACR copper for gas?

GL Plus™ pressurized ACR/Med copper tubing, from Great Lakes Copper Ltd., is available in 10,12, and 20 ft. lengths, and a variety of sizes, both Type L and Type K, is specially cleaned, deburred, purged and pressurized with nitrogen gas, and features easy to remove, installer friendly, form-fitting plugs.

Can you bend ACR copper?

It is possible to physically bend drawn general purpose (H58) tubing, but the result is not acceptable. Bending H58 is not recommended by the tubing manufactures. Only Soft Anneal (O60) or Light Drawn (H55) should be used when field bending ACR Type L or Type K copper tube.

Why are some ACR tubing lines insulated?

Why are some ACR tubing lines insulated? To keep the refrigerant from absorbing heat and to prevent condensation from forming on the line. … Lever type tube benders may also be used.

What is the wall thickness of ACR tubing?

Description: ACR Tubing. Outside Diameter 1-1/8 Inch. Wall Thickness 0.05 Inch.

Why is ACR tubing capped at both ends?

During the production of the copper tube, the inside of the tube has been cleaned and dried before being sealed at both ends to ensure that it remains that way. You must check to make sure that the refrigerant that is going to be used does not react with the copper.

What are the 4 types of copper tubing?

• Type K Copper Pipe. Of all copper pipe types, Type K has the thickest walls and is the most durable. …
• Type L Copper Pipe. While not quite as thick as Type K, with a wall thickness of . …
• Type M Copper Pipe. Type M has a wall thickness of . …
• Copper DWV Pipe.

Is copper pipe pure copper?

Copper pipe is almost pure copper manufactured to the requirements of ASTM B 42 – Standard Specification for Seamless Copper Pipe, Standard Sizes.

What size copper tubing is used for HVAC?

Copper tubing used in air conditioning systems ranges from 1/8-inch to 1-3/8 inches in nominal size. The nominal size is the outside diameter of the pipe.

What type of tubing is used for refrigerant piping?

Aluminum, steel, stainless steel, and plastic tubing are used in HVAC and refrigeration applications. Aluminum coils and refrigerant piping are being used. The use of stainless steel may be seen in certain types of ducting and the walls of mechanical parts within an HVAC system.

What does ODF solder mean?

ODF means Outside Diameter Female or it refers to as Solder or Sweat connection.

What is the outside diameter of 1/4 ACR tubing?

ApplicationAir Conditioning, Refrigeration, Natural Gas, LP Gas, Compressed AirInner Tube Diameter1/4″Length20 ftMaterialCopperOuter Tube Diameter3/8″

What is the difference between hard drawn and soft drawn copper?

Soft copper is hard drawn copper that has been heated and annealed. Soft copper has an ultimate Tensile strength of about 32000psi . Hard drawn copper Tensile strength can vary from about 45000psi to 55000psi. Hard wire is stiffer and generally not suitable for wiring except in straight bus applications.

Can ACR tubing be used for propane?

In 1999, the International Association of Plumbing & Mechanical Officials (IAPMO) designated that copper tubing and fittings are allowable for gas-distribution systems, including propane.

What type of copper is used for plumbing?

Type L Copper Pipe: Type L copper pipe is used for interior plumbing, fire protection, and some HVAC applications. It is available in rigid and flexible forms and can be used with sweat, compression, and flare fittings.

Which of the following copper tube types is color coded green?

Tube typeColor codeStandardACRBlueASTM B 280OXY, MED OXY/MED OXY/ACR ACR/MED(K) Green (L) BlueASTM B 819

Why are copper fittings cleaned before soldering or brazing?

It cleans the metal making the solder stick to the fittings and pipe better it cleas oxides and oils. … The longer that copper is kept at the higher brazing temperature, the greater the formation of copper oxide, and nearby valves may be overheated. Why is it important to heat braze joints as quickly as possible?

What size is imperial copper pipe?

Nominal Bore SizeOutside Diameter1″1.112″ / 28.24 mm1-1/4″1.362″ / 34.59 mm1-1/2″1.612″ / 40.94 mm2″2.218″ / 56.34 mm

In what size rolls is soft copper tubing normally available?

In what size rolls is soft copper tubing normally available? Soft copper is normally available 25-ft or 50-ft rolls and in diameters from 3/16 in. to ⅞ in. Why are some ACR tubing lines insulated? To keep the refrigerant from absorbing excess heat.

What PSI can copper pipe hold?

The copper in annealed pipe is softer than the copper in drawn pipe and withstands less pressure. Type M, 3/4-inch drawn copper pipe handles a maximum of 701 pounds per square inch at 100 degrees. The same size and type of annealed copper pipe has a maximum pressure rating of just 337 pounds per square inch.

How much psi can a solder joint hold?

A soldered four-inch Type L joint has a pressure rating of 440 psi. If the plumber in the field decides to braze that joint rather than solder it, the rating will be reduced to 293 psi — the annealed rating.

Why should copper tubing be cut with a tubing cutter instead of a hacksaw?

Why should copper tubing be cut with a tubing cutter instead of a hacksaw? Tubing cutters are preferable because they do not generate chips that can get in the system. Tubing cutters also have the advantage of producing a cut that is perpendicular to the length of the tubing.
