T8 tubes are simply 1 inch in diameter versus the 1.5 inch diameter of T12 tubes. In an effort to make LED tube lights compatible with the internal dimensions of most fixtures, you will find that most LED tube lights feature a T8 or 1 inch diameter. They can indeed be used in T12 fixtures.

What are the standard sizes of fluorescent tubes?

Fluorescent circline tubes are typically 1 and 1/8 of an inch in diameter. Their outside diameter (which is measuring the circle from one end to the other) comes in four options – 6, 8, 12, and 16 inches.

Can you put a T8 bulb in a T12 ballast?

As far as safety is concerned, you can exchange them. If you place T12 tubes in a fixture with a T8 ballast, you will wear out the ballast and have to replace it. If you place T8 tubes in a fixture with a T12 ballast, then the tubes will have a shorter life due to a higher current through the tube.

What's the difference between T5 and T8 LED tubes?

The major physical difference between T5 and T8 light bulbs is the length and diameter of the tube itself. The T5 tends to be slightly shorter than the T8 tube, and is significantly smaller in diameter. This factor is important to consider when looking at your fixture, because the two tubes are not interchangeable.

What is the diameter of a T5 tube?

T5 lamps have a diameter equal to 5 times an eighth of an inch, or 5/8″. These lamps are approximately 40% smaller than T8 lamps, which are one inch in diameter, and almost 60% smaller than T12 lamps, which are 1½” in diameter.

Do T5 bulbs fit in T8 fixtures?

T5 lamps cannot replace T12 or T8 lamps because of differences in physical and electrical characteristics.

Do T8 and T12 bulbs use the same socket?

T12 tubes are 1.5″ in diameter while T8s are just one inch. All other things—socket sizes, lengths, distance between pins—are the same. T8 LED tubes won’t fall out if you try to install them in a T12 fixture—they’ll fit just fine.

How do I identify a T8 bulb?

If the label is missing or illegible, you can measure the diameter to determine the size. The letter “T” will stand for tubular shape and the number will tell you the bulb diameter in eighths of an inch. T8 will have one-inch diameter, the T5 will have a 5/8 diameter, and a T12 will have 12/8 inch or 1.5 inch diameter.

What is the difference between T8 and G13?

A T8 tube is also called a TL-D tube from Philips and a Lumilux tube from Osram. You can recognize a T8 tube from it’s 28mm diameter. The socket is called G13 this because the 2 pins are 13mm apart from each other. . A T8 tube can work on an electronical ballast using a fixture without a starter.

How do you measure the diameter of a light bulb?

To determine a light bulb size, use the full size scale shown (calibrated in eighths). Place edge of the light bulb to be identified on the top end of the scale and measure the approximate diameter by reading the measurement at the opposite edge of the light bulb.

Article first time published on

What is T5 fluorescent tubes?

A T5 is a type of fluorescent tube. It differs from a T12 and a T8 in its diameter. All T5s are 5/8ths of an inch (T8s are exactly 1inch thick and T12s are 12/8ths or 1.5 inches thick). T5s are 16mm in diameter making them the thinnest fluorescent tube out of the three.

Are all T8 bulbs the same?

Like T12 lamps, T8 lamps are available in a variety of color temperatures, including warm (3000 K), neutral (3500 K), cool (4100 K), and very cool (5000 K). … Color temperature may also be included in the designation by replac- ing the zero in the new designation with the first two digits of the CCT.

Is F40 the same as T8?

This means a T8 lamp is 8/8ths of an inch in diameter, or 1 inch. … All F32 and F40 lamps are essentially 4 foot long lamps (47″ if you don’t count the pins). The FR71T12 is actually a 71″ long x 1.5″ diameter lamp that can handle from 80-120w and is typically run at 100w. It uses the different use of the F number.

How many lumens is a T8 fluorescent bulb?

A T8 fluorescent that uses 32 watts of energy typically produces 2500 lumens of light. It’s LED equivalent, while using only 17 watts, produces 2200 lumens. Additionally, T8 LED light bulbs have a lifetime rating of 50,000 hours, more than 3 times longer than 15,000 hour average lifespan of T8 fluorescent lights.

Can a T8 tube replace a T12?

The easiest and lowest price option to replace a T12 is a T8 linear fluorescent. They have become the go-to option for pre-existing T12s. If you still have magnetic ballasts, switching to a T8 will require a ballast swap.

Are fluorescent tubes being phased out?

Legislation being brought forward this month will also include the removal of fluorescent lights from shelves from September 2023. … In addition, the government also plans to start phasing out the sale of high-energy fluorescent lightbulbs, with a view to bringing an end to their sale from September 2023.

Can I replace T8 with LED?

Type A – LED tube has an Integrated Driver for use on Existing Fluorescent Ballast. Type A LED tubes need an existing T8 electronic ballast to operate. … All you need to do is remove the existing T8 fluorescent lamp and install a new T8 LED Type A lamp.

How do I know if my socket is shunted?

1. If your existing light fixture shows positive continuity when testing both contacts on a single socket (usually the meter will beep), there is power flowing between the two contacts, and this is a shunted tombstone.
2. If there is no power between contacts, it is a non-shunted tombstone.

Can you put an LED tube in a fluorescent fixture?

Many LED tubes are “plug and play”, meaning you can just install them like you would a fluorescent bulb. For this to be true, look for bulbs that are “ballast-compatible” meaning that they can use the ballast already installed in your fluorescent fixture to power the LEDs.

What is T8 tube?

The largest category of tube light in widely-available use, T8 tube lights measure 26mm in diameter and are often used for lighting large, wide-open spaces. They’re normally seen in supermarkets, warehouses, garages and offices, although they’re suitable for smaller environments that need plenty of light too.

What does 840 mean on a fluorescent tube?

So for example 840 means the lamp has a CRI of 80% and a colour temperature of 4000K.

Is T5 the same as G5?

Fluorescent G5 tube base types are a two pin fitting located at each of the tube with 5mm between the two pins. The T5 (16mm tube diameter) and T4 (12mm tube diameter) uses the G5 cap fitting.

What is T8 LED tube light?

T8 LED Tube Lights Overview T8 LED tube lights are interior LEDs used to replace T8 Fluorescent lamps. There are three main types of T8 tube lights, with a combination style T8 LED tube available. Each LED tube option is defined by how the LED interacts with the existing fluorescent ballast.

What's the brightest T8 bulb?

The brightest four foot T8-sized LED tube light is the Barrina LED Shop Light Fixture. This tube shines with 5000 lumens using 44 watts. It replaces a 72 watt fluorescent tube.

How do you measure a diameter?

If you know the radius of the circle, double it to get the diameter. The radius is the distance from the center of the circle to its edge. If the radius of the circle is 4 cm, then the diameter of the circle is 4 cm x 2, or 8 cm. If you know the circumference of the circle, divide it by π to get the diameter.

How do I know what size light bulb base?

A further explanation of the light bulb base sizes, you can look at the letter-number references (E12, E17, and E26) to help understand a bulbs base style and size. The first letter designates the shape or form of the base, and the number represents the width of the base (normally in millimeters).

What size is a Type B light bulb?

Length: 1.5 in. – Height: 4.33 in. – Width: 1.5 in.

Are T8 fluorescent bulbs being discontinued?

Even some T8 lamps have been phased out. US Congress has enacted legislation to prohibit the manufacture of these and other inefficient lighting technologies, and is calling for manufacturers to meet minimum efficiency requirements and lumens per watt for new products.

What does the F stand for in fluorescent bulbs?

F = type of lighting. 32 = wattage. T8 = shape. “F” stands for fluorescent, which is the type of lighting.
