So if you’re a minimalist when it comes to processing, higher Qts is indeed better. But if you’re not averse to loading up your midbass with EQ, then you can possibly do better by using a lower Qts (or higher F3, or both) driver with a superior motor design.

What is subwoofer SD?

Sd: The surface area of the cone measured in square centimeters. Vd: This is the maximum amount of linear volume displacement the subwoofer is able to produce. It is the total air volume the subwoofer’s cone will move, measured in cubic meters. The formula Xmax multiplied by the surface area (Sd) is used.

What does XMax mean for subwoofers?

Peak Power Handling = A measure of power that could potentially be managed for short bursts. XMax = The distance a subwoofer voice coil can move in one direction without leaving the magnetic zone a.k.a. how far the woofer can move.

What is QTS Thiele small?

Thiele/Small parameters (commonly abbreviated T/S parameters, or TSP) are a set of electromechanical parameters that define the specified low frequency performance of a loudspeaker driver. … Small of the University of Sydney, who pioneered this line of analysis for loudspeakers.

What is speaker QMS?

Qms is a measurement of the control coming from the speaker’s mechanical suspension system (the surround and spider). … Qes is a measurement of the control coming from the speaker’s electrical suspension system (the voice coil and magnet).

How do you calculate QTS?

Qts: Qts is the total Q of the speaker. It is defined as 1/Qts = 1/Qes + 1/Qms.

What is a high Q for a speaker?

Q (or quality factor) is a unitless number that describes how underdamped an oscillating circuit is. A higher Q value means that the circuit or system has low damping and will ring or resonate for longer.

What is Le mH?

Le = Voice coil inductance measured in millihenries (mH) (measured at 1 kHz). … Vas = The Thiele-Small parameter that measures the overall compliance of a loudspeaker transducer. The Vas is defined as the volume of air that has the same compliance as the driver.

What is the QTS of a speaker driver?

Qts is the total Q of the speaker and is derived from an equation where Qes is multiplied by Qms. The result is divided by the sum of the same. This value can be used as a general guideline in selecting the optimal enclosure type. A Qts of 0.4 or below indicates a speaker well-suited to a vented enclosure.

How does QTS work?

QTS is a one-year course which is needed to work in a state-maintained school. This qualification confirms that you have met the government’s Teaching Standards and is followed by two years of induction in a school. Remember that you will need to decide whether you are going to opt for Primary or Secondary training.

Article first time published on

What is f3 speaker parameter?

f3 is the most meaningful parameter. The lower the f3 parameter the deeper the bass will sound. An f3 below 50 Hz is suitable for a sealed enclosure. … In the frequency response plot, the output SPL, sound pressure level, is based at 1 watt/meter.

What is bl in speaker?

Force Factor (BL) = Flux Density (B) * Length Of Voice Coil (L) The BL Product (aka Force Factor) measures the strength of the speaker motor. Stronger motors are more capable of moving larger diaphragms and, generally speaking, can handle more power.

Do watts matter in subwoofers?

The watt rating is a rough guide to how loud a subwoofer might be able to play, but it doesn’t have to be louder. You always control the volume. In fact, a 1,000-watt sub may sound better at “regular” room volumes than a 100-watt sub. Though quite common, 100-watts really isn’t that much when we’re talking subs.

Does subwoofer magnet size matter?

The bigger the magnet, the stronger the potential driving force of the speaker (assuming the magnetic strength of the magnet is constant). Small magnets are for small speakers and produce, by nature, “weaker sound”, while bigger magnets make bigger speakers capable of producing louder sound.

What is an Underhung subwoofer?

An overhung voice coil is taller than the height of the gap, while an underhung voice coil is shorter than the height of the gap. Overhung voice coils are the most common.

What is infinite baffle?

In conceptual terms an infinite baffle is a flat baffle that extends out to infinity – the so-called “endless plate”. A genuine infinite baffle cannot be constructed but a very large baffle such as the wall of a room can be considered to be a practical equivalent.

What is EBP speaker box?

Efficiency Bandwidth Product (EBP) is a number which shows the trade-off between efficiency and bandwidth of a driver. It is useful in determining if a driver is suited for a sealed or vented box and is also used to determine suitability for horn loading.

How do you calculate speaker volume?

You simply measure the height, width and depth (in inches), multiply them together and then divide that number by 1728. If the box has internal measurements of 6″ high*18″ wide*12″ deep then the volume of the box is 1296/1728=. 75 ft^3.

What does Bass Q factor mean?

The Q factor is the width of a frequency the lower the Q factor the wider the frequency the higher Q the more narrow it gets in other words if you only want to push or cut 100Hz use a very high Q if you want to effect the frequencies just below 100Hz and just above 100Hz as well as 100Hz use a lower Q factor.

How do you calculate QMS?

The traditional way to measure Q is to measure the bandwidth between the -3dB frequencies, then divide the resonant frequency by the bandwidth. For example, if resonance is at 29.6Hz and -3dB frequencies are at 25Hz and 35Hz, then Q is 2.96. This would be Qms in the calculations.

Which frequency is bass?

Frequency SubsetFrequency RangeBass60 to 250 HzLower Midrange250 to 500 HzMidrange500 Hz to 2 kHzHigher Midrange2 to 4 kHz

What is VB subwoofer?

Vb is the box net volume.

Is Xmax the same as excursion?

Nope. They’re not actually directly related. Xmax is more how stiff the suspension is for the speaker to reach a limit with a certain amount of power. The hertz is louder in the same frequency band.

What is F3 subwoofer?

F3 is the frequency where the output is 3 db lower. If your Lp crossover is set at 80hz then it is 3db lower at 80hz. If the box has an f3 of 30hz that is the point it starts dropping off.

What is Fo Hz?

Interpretation of Catalogue Specifications. LOWEST RESONANCE FREQUENCY (fo) This frequency is usually referred to as ‘f zero’ and expressed in units of Hertz. This can be regarded as an element which determines the lowest reproducible frequency.

Is Thiel Audio still in business?

THIEL Audio was an American privately held high performance loudspeaker (hi-end audio) manufacturer founded in Lexington, Kentucky, but now based in Nashville, Tennessee. … Thiel ceased operations in 2018.

How much does QTS cost?

The fee is comprised of two parts: There is a non-refundable fee of £1000 for the full selection stage. This includes £250 for the eligibility interview and £750 for the suitability and approval visit. Schools will be invoiced with the appropriate amount after the eligibility interview.

What is QTS certification?

Qualified Teacher Status (QTS) is a professional qualification awarded by the National College of Teaching and Leadership (NCTL) when a person can prove that they meet all of the Teachers’ Standards and criteria.

How long does QTS last?

Recently qualified teachers can undertake short term supply for a period of 5 years after being awarded QTS (i.e. their graduation). Periods of a full term or more can be counted towards the induction period so most people will complete the equivalent of a full year’s induction during this 5 year period.

What sounds better ported or sealed?

The sound waves are reproduced more accurately than with a ported enclosure but the subwoofers may require slightly more power from the amplifier to get the woofers to move as much as they would in a ported enclosure. Sealed enclosures are generally smaller and easier to build because there is no port to tune.

What does it mean when a woofer unloads?

This is what gives you the bigger and louder sound out of one box because there are two different mechanisms that are moving the air — the port and the woofer. … Essentially, this can damage the suspension of the woofer because of excessive cone travel (called “unloading”).
